VMB8APS150 DN50 Kvs=40
SKU
VMB8APS150
3-way globe mixing valve PN16
DN50 and Kvs=40 and external threaded connections
G25 cast iron body and internal brass parts
Fluid temperature -10/150 °C
DN50 and Kvs=40 and external threaded connections
G25 cast iron body and internal brass parts
Fluid temperature -10/150 °C
VMB8APS150 is a 3-way globe mixing valve with PN16, DN50, Kvs=40 and external threaded connections.
G25 cast iron valve body. Brass plug with Contoured profiling on the direct path and V-port type on the corner path. Stem in CrNi steel with threaded end M8. Seal of the stem with EPDM O-ring and graphite teflon scraper.
Used for the control or interception of water or glycol water with a mixture up to 50% in air-conditioning systems, thermoventilation and heating, civil and industrial, and in machines for the heat treatment of products.
G25 cast iron valve body. Brass plug with Contoured profiling on the direct path and V-port type on the corner path. Stem in CrNi steel with threaded end M8. Seal of the stem with EPDM O-ring and graphite teflon scraper.
Used for the control or interception of water or glycol water with a mixture up to 50% in air-conditioning systems, thermoventilation and heating, civil and industrial, and in machines for the heat treatment of products.
| Valve body | Cast Iron |
|---|---|
| Plug | Brass |
| PN | 16 |
| T Fluid min [°C] | -10 |
| T Fluid max [°C] | 150 |
| Leakage [% Kvs] | 0,03 |
| Leakage by-pass [% Kvs] | 2 |
| Stroke [mm] | 16,5 |
| Valve type | 3 way |
| DN [mm] | 50.00 |
| Kvs | 40.00 |
| Kvs by-pass | 40.00 |
| Connection | External threaded |
| Fluid | Water |
| Max Differential Press. [kPa] | 200 |
| Connection size | 2 1/4" M (GAS UNI-ISO 228) |
| Application | HVAC-R |
